蛭石布

@The Vermiculite cloth is produced by high quality texturized fiberglass cloth or ceramic fiber cloth.@It can be made to different types to meet different environments according to the customer needs. The working temperature is 1050°C (1920°F), and has good appearance and thermal insulation.蛭石布是以优质膨体无碱玻纤布或陶纤布为基布,经整理、涂层而成。根据不同的客户需求,可以做成各种形式,使其适应各种使用条件。最高使用温度可达1050°C,具有良好的外观和耐热性。根据不同的使用环境和要求,也可以采用其它涂层材料:石墨、硅胶、丙烯酸等
  • 蛭石布简介

        北京费普福工程技术有限公司蛭石布是以优质膨体无碱玻璃纤维布或陶瓷纤维布为基布,经整理、涂层而成。根据不同的客户需求,可以做成各种形式,使其适应各种使用条件。最高使用温度可达1400°C具有良好的外观和耐热性。燃烧性能可达A1级(GB8624).是非常优良的防火材料。

        根据不同的使用环境和要求,也可以采用其它涂层材料:石墨、硅胶、丙烯酸等。

    蛭石布规格表

    规格厚度(mm)幅宽(mm)单重(g/m2)基布纹路卷长(m/roll)
    CV2.0210001200陶纤布平纹30
    CV3.0310001650陶纤布平纹30
    GV0.80.81000800玻纤布缎纹50
    GV1.41.410001150玻纤布平纹50
    GV1.71.710001300玻纤布平纹30
    GV2.0210001400玻纤布平纹30

    备注:以上厚度、幅宽与单重三项数据在实际生产中均会有±10%的变化范围;

     蛭石布应用范围

    • 防火挡烟布

    • 接火花布

    • 灭火毯

    • 柔性膨胀节

    • 各种保温及隔热材料等

    Introduction

        The Vermiculite cloth is produced by high quality texturized fiberglass cloth or ceramic fiber cloth. It can be made to different types to meet different environments according to the customer needs. The working temperature is 1050°C (1920°F), and has good appearance and thermal insulation.

        Compared to uncoated cloth, vermiculite coated cloth provides increased resistance to high temperature, flame, and abrasion. In addition, the vermiculite film helps to seal against gases and liquids. Vermiculite Coated Cloth is completely non-flammable.

    Specifications


    Type

    Thickness

    (mm)

    Width

    (mm)

    Weight(g/m2)

    Basic

    Cloth

    Weave

    Roll Length

    (m/roll)

    CV2.0

    2.0

    1000

    1200

    Ceramic

    Plain

    30

    CV3.0

    3.0

    1000

    1650

    Ceramic

     Plain

    30

    GV0.8

    0.8

    1000

    800

    Fiberglass

     Satin

    50

    GV1.4

    1.4

    1000

    1150

    Fiberglass

     Plain

    50

    GV1.7

    1.7

    1000

    1300

    Fiberglass

    Plain

    30

    GV2.0

    2.0

    1000

    1400

    Fiberglass

    Plain

    30


    NoteThe above thickness, width and weight data are there in the actual production range of±10%


    Application

    • Fire and smoke proofing cloth

    • Sparkle preventive cloth

    • Fire blanket

    • Flexible expansion joints

    • Heat preservation and thermal insulation materials

    • Oven door seals, Electrical insulation, Hose protection, Cable protection, Pipe wrap, High temperature gasket

     做防火就是做良心,做保温就做功德。北京费普福工程技术有限公司蛭石布呵护您的爱物!
